This multi-functional digital clamp meter features 3 5/6-digit LCD (35.5x25.5mm, max 5999 display) with dual white/orange backlight. It supports true-RMS testing and covers DCV/ACV (up to 600V, ±1.0%-1.2% accuracy), ACA (up to 600A, ±2.5%), resistance (up to 60MΩ), capacitance (up to 60mF) & frequency (10Hz-100MHz). Equipped with NCV, torch, auto-range/power-off, overload protection & data hold, it runs on 2 AAA batteries, weighing 193g with ∮20mm jaw and full standard accessories.
| Item No: | MMDT-2017B |
| DCV: | 600m-6-60-600V ±1.0% |
| ACV: | 600m-6-60-600V ±1.2% |
| ACA: | 6-60-600A ±2.5% |
| OHM: | 60-600-6K-60K-600K-6M-60MΩ ±1.5% |
| Capacitance: | 60n-600n-60μ-600μ-6m-60mF ±5.0% |
| Frequency: | 10Hz-100MHz ±1.5% |
| Temperature: | -40-1000ºC ±3.0% -40-1832ºF ±3.0% |
| 3 5/6 digit LCD, Max display 5999 LCD size : | 35.5x25.5mm |
| Power supply: | 1.5V*2 battery (AAA) |
| Product size: | 203×68×33mm |
| Jaw Caliber: | ∮20mm |
| Product Weight: | Around 193g( with battery) |
| Standard Accessories: | meter gift box, test lead, , battery, manual |
| Auto range: Yes Auto power off: Yes Low-Voltage Display: Yes Overload protection: Yes Diode Test: Yes,display Approximate VoltageContinuity: Yes<br style="--un-rotate: 0; --un-rotate-x: 0; --un-rotate-y: 0; --un-rotate-z: 0; --un-scale-x: 1; --un-scale-y: 1; --un-scale-z: 1; --un-skew-x: 0; --un-skew-y: 0; --un-translate-x: 0; --un-translate-y: 0; --un-translate-z: 0; --un-pan-x: ; --un-pan-y: ; --un-pinch-zoom: ; --un-scroll-snap-strictness: proximity; --un-ordinal: ; --un-slashed-zero: ; --un-numeric-figure: ; --un-numeric-spacing: ; --un-numeric-fraction: ; --un-border-spacing-x: 0; --un-border-spacing-y: 0; --un-ring-offset-sh High Performance Clamp Meter: This auto-ranging clamp meter can accurately measure AC/DC voltage up to 600V, AC current up to 600A (not for DC current), NCV(>90V ACvoltage), LPF,Diodes, Continuity function. High current can be measured, more widely used, more accurate data. Easy to carry and use, it also has a backlight and automatic shutdown function, which is a must for home improvement, industry, factory, solving automotive or electrical problems  | |
