The DIG6500iE gasoline inverter generator is an ideal choice for professionals and businesses that require a high-capacity, reliable, and versatile power source with the convenience of portability and the assurance of environmental compliance.
| Item No. | DIG6500iE | |
| Engine | Frequency: | 50/60 Hz |
| Rated AC output: | 5.5 kw | |
| Max.AC output: | 6.5 kw | |
| Rated AC Voltage: | 100,120,230,240 | |
| Power Factor: | 1 | |
| Engine Model: | XY188F-1 | |
| Type: | Forced Air-cooled,4-stroke,OHV | |
| Displacement: | 389 cc | |
| Bore x Stroke: | 88x64mm | |
| Max.Output: | 7.2KW/3600rpm | |
| Fuel: | Unleaded Gasoline | |
| Generator | Fuel Tank Capacity: | 18.5 L |
| Contunous Operating Hours: | 4.5h (100% Load) | |
| Oil: | SAE 10W-30 Above SJ Grade | |
| Oil Capacity: | 1.0 L | |
| Ignition System: | C.D.I | |
| Starting System: | Electric Starter | |
| Operating Noise Level (7m): | 65 dB | |
| Dimensions | Net Dimension: | 750*537*630 mm |
| Overall Dimension: | 780*570*620 mm | |
| Net weight: | 89 | |
| Gross Weight: | 98 | |
| 20GP/40GP/40HQ: | 84/180/240 | |
| Cert. | EPA | |
| Standard Features | Large-capacity air cleaner: | N |
| Large-capacity fuel tank: | N | |
| Large-capacity fuel muffle: | Y | |
| Fuel indicator: | Y | |
| Voltmeter: | N | |
| Auto voltage adjustor | Y | |
| Oil alert system | Y | |
| Circuit breaker without fuse: | Y | |
| Circuit protector: | Y | |
| Battery tray: | N | |
| 4-wheel dolly kit: | N | |
High Power Output: With a rated AC output of 5.5 kW and a maximum output of 6.5 kW, this generator is capable of powering more demanding applications.
Voltage Flexibility: It can provide power at various voltages (100, 120, 230, 240 V), making it suitable for diverse electrical systems.
Robust Engine: The XY188F-1 engine with a displacement of 389 cc ensures powerful and reliable performance.
Long Operating Time: The 18.5 L fuel tank allows for up to 4.5 hours of continuous operation at full load, reducing the need for frequent refueling.
Low Noise Operation: At 65 dB at 7 meters, the generator offers a quieter operation compared to many other generators in its class.
Safety Features: Equipped with an oil alert system, circuit breaker, and circuit protector for safe and secure operation.
Automatic Voltage Regulation: The auto voltage adjustor ensures a stable power supply, protecting connected devices from voltage fluctuations.
Environmentally Friendly: Certified by the EPA, indicating compliance with strict environmental standards.
User-Friendly Interface: Features like the fuel indicator and the absence of a large-capacity fuel muffle contribute to ease of use.
