The 154F is a single-cylinder, four-stroke, side valve (SV) gasoline engine that offers a balance of power and efficiency for various applications.It is a robust and efficient power solution for a variety of applications, combining power, efficiency, and ease of use in a compact package.
Item No | 154F |
Engine type | sinlge cylinder ,4-stroke ,SV |
Bore*stroke | 54 x 38(mm) |
Volume | 87cm³ |
Compression ratio | 7.7:1 |
Maximum power output | (2.4HP)1.8kw |
Rated power output | (1.8HP)1.3kw |
Maximum torque | 3.5N.m |
Ignition system | T.C.I (Transistor magneto) |
Starting system | Recoil |
Engine oil system capacity | 0.37L |
Fuel capacity | 1.6L |
Min.fuel consumption | ≤290g/kw/h |
Power output type | crankshaft 1:1 |
The output axle steering | Left |
Air cleaner | Semi-dry,oil bath, dual ,silent, cyclone |
Dimensions | 340 x 290 x 340(mm) |
Net weight | 10kgs |
High Compression Ratio: A 7.7:1 compression ratio ensures efficient combustion and better power output.
Versatile Power: With a maximum power output of 2.4 HP (1.8 kW) and a rated power output of 1.8 HP (1.3 kW), the engine is suitable for a range of applications.
Robust Torque: The 3.5 N.m of maximum torque provides the necessary force for tough tasks.
Reliable Ignition and Starting: The T.C.I ignition system and recoil starting system ensure quick and reliable engine starts.Fuel Efficiency: The engine is designed to be fuel-efficient with a minimum fuel consumption rate of ≤ 290 g/kw/h.
Compact and Lightweight: With dimensions of 340 x 290 x 340 mm and a net weight of 10 kgs, the engine is portable and easy to handle.
Easy Maintenance: The semi-dry, oil bath, dual, silent, cyclone air cleaner system is low-maintenance and ensures longer engine life.
1:1 Power Output: The crankshaft 1:1 power output type provides a direct and efficient transfer of power.
Left-Hand Output Shaft: The left-hand output shaft steering is versatile for various machinery configurations.
Suitable for Multiple Applications: Ideal for use in equipment such as portable generators, water pumps, lawn mowers, and more.
