The WP80D 3-inch diesel water pump is a high-capacity, heavy-duty solution for water management in professional settings. Its combination of power, portability, and durability makes it an excellent choice for a wide range of applications requiring a reliable and efficient water pumping solution.
| Item No | WP80D | |
| Type | Single cylinder,4stroke,air-cooled;diesel engine | |
| Work capacity | 296cm3 | |
| Max.Output | 5.7HP/3000RPM | |
| Starting system | Recoil/Electric | |
| Fuel tank capacity | 3.5L | |
| Engine Oil system capacity | 1.1L | |
| Water Pump | ||
| Diameter of outlet(inch) | 3 inch | |
| Max.delivery lift | 28m | |
| Suction height | 7m | |
| Max.water displacement | 36cm3/h | |
| Size and Weight | ||
| Overall dimension | 560*450*550(mm) | |
| Dry weight | 47kg | |
Powerful Diesel Engine: The single cylinder, 4-stroke, air-cooled diesel engine with a work capacity of 296 cm³ delivers 5.7 HP, ensuring robust performance for heavy-duty applications.
High Maximum Output: The pump's 5.7 HP at 3000 RPM output provides exceptional power for moving large volumes of water quickly and efficiently.
Dual Starting Options: The recoil and electric starting systems offer flexibility and convenience, catering to different user preferences and situations.
Generous Fuel and Oil Capacities: With a 3.5 L fuel tank and 1.1 L engine oil capacity, the pump is designed for extended periods of operation without frequent refueling or oil changes.
Large Outlet Diameter: The 3-inch outlet diameter is suitable for high-volume water flow, making it ideal for larger-scale projects and applications.
Extended Delivery Lift: Capable of a max. delivery lift of 28 meters, the pump can handle significant vertical water movement, perfect for challenging terrains.
Deep Suction Capability: The 7-meter suction height allows the pump to draw water from deep or distant sources, enhancing its versatility.
High Water Displacement: With a max. water displacement of 36 cm³/h, the pump is equipped to handle large-scale water transfer tasks.
Compact yet Powerful: Despite its powerful performance, the pump maintains a compact size, making it portable and suitable for various environments.
Versatile Applications: Ideal for construction sites, mining operations, agricultural irrigation, flood control, and other heavy-duty water management tasks.
