| Model No. | 3TGQ-4E |
| Engine model | 170F |
| Engine Type | Single Cylinder,4-Stroke, Forced Air-Cooled,gasoline |
| Displacement | 212 cc |
| Maximum power and speed hp(kw)rpm | 7.5(5.6)/1800 |
| Fuel Tank Capacity | 3.6 L |
| Starting System | Recoil |
| Handle bar adjustable range (Vertical) | 360° |
| Tilling ditch Width | 250 mm |
| Tilling ditch Depth | >100mm |
| Working box speed | 420-620 r/min |
| Shift Gear | (1,0,-1)*2 |
| Transmission | Belt + Chain |
| Tire | 3.5-12 |
| Blades | Ditching and Earth cultivating knife (2 pairs) |
| Certification | CE, EMC,EURO V |
Main functions: rotary tillage , weeding, furrowing pre-planting
Scope of application: garden, greenhouse, sloping field, paddyfield etc.
1. 170F engine, with more strong power
2. Novel tillage method, rotary blades positive inversion on same axis, low handling strength, more effect of rotary tillage
3. Engine mounting position down,It is more easy for operation.
4. Increased rpm,it is more effective for ditching and ridging.
5. Use solid tire in this mechine,never bursted,never air leakage.It allows longer life time.
6. Can adjust the depth roller to meet different soil texture and diffrent terrain requirement.
