The 10HP Diesel Power Tiller (DT1350F) is a powerful assistant in agricultural and horticultural work. In vast fields, it quickly turns the soil with its 10HP powerful engine and an adjustable working width of 1050-1400mm, creating ideal conditions for sowing and crop growth. Garden enthusiasts will find that this tiller is also suitable for soil preparation in flower beds and vegetable gardens, keeping the soil soft and well-ventilated to promote healthy plant growth. For the reclamation of new land or the initial cultivation of uncultivated land, the DT1350F can quickly break up hard soil layers, laying a solid foundation for subsequent agricultural activities. Equipped with 500-12 heavy-duty pneumatic tires and a manual recoil start system, it ensures mobility on various terrains and the convenience of easy operation. Whether professional farmers or home gardening enthusiasts, everyone can easily handle this tiller and enjoy an efficient and convenient tilling experience.
| Item No | DT1350F |
| Engine Model | 186FA |
| Engine Type | Single Cylinder, Vertical,4-Stroke, Forced Air-Cooled Diesel |
| Displacement | 418CC |
| Bore x stroke | 86*72mm |
| Fuel tank capacity | 5.5L |
| Starting System | Recoil Start(Hand Start) |
| Rated Power | 9.0HP (6.6KW)/3600 RPM |
| Max Power | 10HP (7.4KW)/3600 RPM |
| Working width | 1050-1400 (mm) |
| Working depth | 100-300 (mm) |
| Gear Shifting | 2 Forward , 1 Reverse |
| Blades Type | 32 Pcs/(3+1)Group×4PCS (Z041) |
| Gearbox | cast-iron GEARBOX |
| Transmission | Gear-Driven |
| Transmission oil capacity | 1.65L ( transmission) / 1.1 L (engine) |
| Wheel | One pair of 500-12 wheels |
| Certification | CE, EMC |
Robust Engine: The single cylinder, air-cooled diesel engine is built to last and perform under challenging conditions.
Adjustable Working Width and Depth: The tiller's ability to adjust its working width and depth makes it versatile for various soil types and cultivation tasks.
Efficient Power Output: With a rated power of 9.0HP and a maximum power of 10HP, the tiller is capable of handling heavy tilling work efficiently.
Reliable Starting System: The recoil start ensures the tiller can be easily started even in adverse conditions.
Durable Gearbox: The cast-iron gearbox provides strength and longevity, reducing the need for frequent replacements.
Gear-Driven Transmission: This system ensures smooth and efficient power delivery to the tilling blades.
Ample Fuel Tank: The 5.5L fuel tank capacity supports longer working periods, enhancing productivity.
Sufficient Oil Capacity: Adequate transmission and engine oil capacities ensure the tiller runs smoothly and reduces wear.
Versatile Gear Shifting: The 2 forward and 1 reverse gear shifting allows for easy navigation in different field conditions.
High-Quality Blades: The 32 pieces of blades in (3+1) group configuration provide effective tilling and soil turning.
Sturdy Wheels: The 500-12 wheels offer stability and ease of movement over uneven terrain.
Safety and Emission Compliance: With CE and EMC certifications, the tiller meets European safety and environmental standards.
