Item No. | GT800A-3 |
Engine Model | 170F |
Engine Type | OHV,25°Tilt,single cylinder, forced air cooling,4-stroke |
Displacement | 212CC |
Bore x stroke | 70*55mm |
Fuel tank capacity | 3.6L |
Starting System | Recoil Start |
Rated Power | 7.0HP (5.0KW)/3600 RPM |
Max Power | 7.5HP (5.5KW)/3600 RPM |
Working width | 800-1100 (mm) |
Working depth | 100-300 (mm) |
Gear Shifting | 2 Forward , 1 Reverse |
Blades Type | 24 Pcs/4Pcs×3(2+1)Groups (Z065) |
Gearbox | cast-iron GEARBOX |
Pulley | Double pulley |
Transmission | Belt |
Transmission oil capacity | 0.95 L ( transmission) / 0.6 L (engine) |
Wheel | One pair of 400-8 wheels |
Certification | CE, EMC,EURO V |
Simple - easy to use engagement levers and simple recoil starting
Smooth - Soil finishes with table-like smoothness
Dependable - Gear drive transmission, forged tines, and 7.5HP 4 cycle engine
Stable - Low center of gravity and rear mounted tines for easy control and stability in the row
It is the perfect tool for pre-planting ground preparation, as well as many other tasks during the gardening season, such as cultivating between garden rows. With a heavy-duty gearbox, fingertip throttle control and a clutch handle, it provides a consistent transmission of power to tines under varying soil conditions.
