Engineered for demanding agricultural and landscaping tasks, the 192F Micro Tiller delivers exceptional power, durability, and efficiency.
Featuring a rugged single-cylinder, 4-stroke, forced air-cooled diesel engine, this tiller is built to tackle tough soil conditions with ease while offering superior fuel economy.
Its substantial 499cc displacement (Bore x Stroke: 92x75mm) generates an impressive 16 HP (11.9 kW) at 3600 RPM, providing the muscle needed for deep tiling and extensive land preparation.
| Item No.: | DT500Q |
| Engine Model: | 192F |
| Engine Type: | Single Cylinder, 4-Stroke, Forced Air-Cooled Diesel |
| Displacement: | 499CC |
| Bore x Stroke: | 92*75mm |
| Fuel Tank Capacity: | 5.5L |
| Starting System: | Electric Start |
| Max Power: | 16HP/3600 RPM |
| Working Width: | 900-1350 (mm) |
| Working Depth: | 100-300 (mm) |
| Gear Shifting: | 3 Forward , 1 Reverse |
| Blades Type: | 32 Pcs/(3+1)Group×4PCS |
| Gearbox: | Cast-Iron GEARBOX |
| Transmission: | Gear-Driven |
| Attachments: | Front Wheels 5.0-8, Rear Wheels 5.0-12; Two Iron Wheels; |
Effortless Electric Start: Get working quickly and conveniently with the reliable electric starting system.
Superior Tilling Performance: Handle a wide range of tasks with a working width of 900-1350 mm (35-53 inches) and a working depth of 100-300 mm (4-12 inches).
Advanced Blade System: Equipped with 32 high-strength blades configured as (3+1) groups x 4 pieces, ensuring thorough soil pulverization and excellent seedbed preparation.
Versatile Maneuverability: Features 3 Forward gears and 1 Reverse gear for precise control in any situation.
Stable & Robust Chassis: Comes equipped with front wheels (5.0-8) and rear wheels (5.0-12), plus two additional iron wheels for enhanced stability and traction on challenging terrain.
