4-Cycle, 178F engine provides the necessary strength for tilling your soil
With a 1050-1400mm tilling width, self-sharpening steel tines plow while maintaining blade edge
Heavy duty pneumatic tires easily maneuver through tough landscapes
Manual recoil easy start fuel delivery system
Can travel forward and in reverse, allowing for maximum mobility in a variety of conditions
| Item No.: | DT1050D |
| Engine model: | 178F |
| Engine type: | Single Cylinder, 4-Stroke, Forced Air-Cooled Diesel |
| Displacement: | 296CC |
| Bore x stroke: | 78*64mm |
| Fuel tank capacity: | 3.5L |
| Starting system: | Recoil Start(Hand Start) |
| Rated Power: | 6.0HP (4.4KW)/3600 RPM |
| Max Power: | 6.5HP (4.8KW)/3600 RPM |
| Working width: | 1050-1400 (mm) |
| Working depth: | 100-300 (mm) |
| Gear shifting: | 2 Forward , 1 Reverse |
| Blades type: | 32 Pcs/(3+1)Group×4PCS |
| Gearbox: | cast-iron Gearbox |
| Transmission: | Gear-Driven |
| Transmission oil capacity: | 1.65L ( transmission) / 1.1 L (engine) |
| Wheel: | One pair of 400-8 wheels |
Powerful 296CC 4-Stroke: With a 296CC displacement, this tiller cultivator provides outstanding performance for tasks in vegetable gardens, flower beds, or home gardens.
Continuous Operation: The enlarged heat dissipation holes prevent overheating and stalling. High-quality tiller keep engine-damaging dirt out, ensuring the garden tiller's smooth operation. The tough alloy metal gearbox maintains performance in various conditions.
Efficient Work: Equipped with four tines for effective plowing, our tiller features a cultivation width of 1050-1400 mm and a depth of 100-300mm. It handles both sowing and plowing efficiently. Adjustable skid assembly allows you to set its height or depth, while the large drive wheels make it easy to move on the land with reduced resistance.
Easy to Handle: The stand-up operation makes tilling effortless and ergonomic. The thickened and long pull cord ensures reliable starts, while handle-mounted switches and brakes provide better control. A protective shield above the tines prevents soil, rocks, or debris from splashing and causing harm.
