Powered by a 212CC WM170F - 2 - L/P engine, this tiller generates a maximum power of 7 hp (5.1 kw) at 1800 rpm. Measuring 1600×750×880 mm, it features a ditching width of 290 - 320 mm, a tilling width of 420 - 650 mm, and a tilling depth of at least 100 mm.
It has a walking gearbox with forward (H, L), neutral, and reverse (H, L) gears, as well as a tilling gearbox with high and low drive ratios (H, L). The driving system combines gears and belts, with the walking gearbox requiring 1.5 L of transmission oil and the tilling gearbox 1.2 L. Supplied with 5 ditching blades, 3 groups of 3 rotary blades, a set of 30mm iron wheels, and a set of 3.5 - 6 rubber tyres, this tiller ensures efficient and adaptable soil cultivation in different scenarios.
| Item No.: | GT650 |
| Engine model: | WM170F-2-L/P(212CC) |
| Max Power: | 7hp（5.1kw）/1800rpm |
| Body size: | 1600×750×880mm |
| Tilling scope ditching width： | 290～320mm |
| tilling width： | 420～650mm |
| Tilling depth: | ≥100mm |
| Gear shifting walking Gearbox： | forward(H、L)、0、reverse(H、L) |
| Tilling Gearbox : | high drive ratio（H、L）,low drive ratio (H、L) |
| Driving model: | gear+belt |
| Transmission oil capacity walking gearbox: | 1.5L |
| Tilling Gearbox： | 1.2L |
Powerful 212CC 4-Stroke: With a 212CC displacement, this tiller cultivator provides outstanding performance for tasks in vegetable gardens, flower beds, or home gardens.
Continuous Operation: The enlarged heat dissipation holes prevent overheating and stalling. High-quality tiller keep engine-damaging dirt out, ensuring the garden tiller's smooth operation. The tough alloy metal gearbox maintains performance in various conditions.
Efficient Work: Equipped with four tines for effective plowing, our tiller features a cultivation width of 650 mm and a depth of 100mm. It handles both sowing and plowing efficiently. Adjustable skid assembly allows you to set its height or depth, while the large drive wheels make it easy to move on the land with reduced resistance.
Easy to Handle: The stand-up operation makes tilling effortless and ergonomic. The thickened and long pull cord ensures reliable starts, while handle-mounted switches and brakes provide better control. A protective shield above the tines prevents soil, rocks, or debris from splashing and causing harm.
