This 9.8HP outboard motor features a 2-cylinder 169cc engine, with a full throttle operating range of 4000-5000 RPM, making it an ideal power solution for small boats like dinghies and fishing boats that require reliable and efficient performance.
Equipped with a tiller control system and manual starting, it offers straightforward operation, while the manual tilt function and forward-neutral-reverse gear positions enhance maneuverability, suitable for both novice and experienced boaters in calm water conditions.
| Item No.: | T9.8 |
| N.W: | S:27.8 L:29 |
| Full throttle operating range: | 4000-5000 |
| Maximum output: | 9.8HP |
| Idea speed ( in neutral): | 900-1000 |
| Engine type: | 2 |
| Engine type: | 169 |
| Bore x stroke: | 50.0*43.0 |
| Control system: | Tiller |
| Gear position: | Forward-neutral-reverse |
| Gear ration: | 2.08（27/13） |
| Trim and tilt system: | Manual tilt |
| Integral fuel tank capacity: | 12 |
| Ignition system: | CDI |
| Gear oil capacity: | 160 |
| Propeller options: | 8.9*8.5 |
Power System: The motor is powered by a 2-cylinder engine with a displacement of 169cc, matched with a bore x stroke of 50.0*43.0mm. It delivers a maximum output of 9.8HP, providing sufficient power for small boats to navigate smoothly. The neutral ideal speed of 900-1000 RPM ensures stable idling, and the CDI ignition system guarantees quick and reliable ignition, reducing startup failures and improving overall operating efficiency.
User-Friendly Operation Design: It adopts a tiller control system, allowing the operator to easily adjust the direction and speed of the boat with one hand, ensuring flexible operation. The manual starting system is simple in structure and easy to maintain, avoiding the trouble of electric starting system failures. Additionally, the 2.08 (27/13) gear ratio optimizes power transmission, making the boat start and accelerate more smoothly.
